About Product
The Afinox INFINITY Start 80 Roll-In Blast Chiller & Freezer is a durable, heavy-duty solution for transporting packages, supplies, and equipment. Designed for demanding environments, it supports loads up to 1,102 lbs. Ideal for use in 240 minutes, this unit helps deliver safety, efficiency, and precision.
Key highlights:
- 40°C ambient temperature rating for reliable performance in hot environments
- Holds (5) GN 1/1 trolleys or (3) GN 2/1 full-size pan trolleys
- 9-inch touchscreen control for user-friendly operation
- Chilling capacity: 1,102 lbs from 194°F to 37°F in 90 minutes
- Freezing capacity: 992 lbs from 194°F to -0.4°F in 240 minutes
- 7 programmable cycles: blast chill, shock freeze, thaw (automatic/manual)
- Multipoint core probe with 4 sensor points for precise readings
- Multilevel and defrosting functionality
- Removable electronic panel simplifies maintenance
- AISI 304 stainless steel body for durability and hygiene
- USB and SD card access for HACCP data download and tutorial videos
The Afinox INFINITY Start 80 Roll-In Blast Chiller & Freezer is a durable, heavy-duty solution for transporting packages, supplies, and equipment. Designed for demanding environments, it supports loads up to 1,102 lbs. Ideal for use in 240 minutes, this unit helps deliver safety, efficiency, and precision.
Key highlights:
- 40°C ambient temperature rating for reliable performance in hot environments
- Holds (5) GN 1/1 trolleys or (3) GN 2/1 full-size pan trolleys
- 9-inch touchscreen control for user-friendly operation
- Chilling capacity: 1,102 lbs from 194°F to 37°F in 90 minutes
- Freezing capacity: 992 lbs from 194°F to -0.4°F in 240 minutes
- 7 programmable cycles: blast chill, shock freeze, thaw (automatic/manual)
- Multipoint core probe with 4 sensor points for precise readings
- Multilevel and defrosting functionality
- Removable electronic panel simplifies maintenance
- AISI 304 stainless steel body for durability and hygiene
- USB and SD card access for HACCP data download and tutorial videos
Specifications
| Weight | 1806 lb |
| Blast Chilling Capacity | 1102 lb |
| Freezing Capacity | 992 lb |
| Pan Capacity | 100 (GN 2/1 steam table pans) |
| Voltage | 220V |
| Hertz | 60Hz |
| Phase | 3 Ph |
| Amperage | 23 Amps |
| Refrigerating Power | 14970 W |
| Noise Level | 124 dB |
| Number of Probes | Multipoint core probe (4 reading points) |
| Temperature Range (Chill) | From 194°F to 37°F in 90 minutes |
| Temperature Range (Freeze) | From 194°F to -0.4°F in 240 minutes |
| Control System | 9 in Touchscreen |
| Refrigerant Gas | R404A |
| Installation Type | Freestanding |
| Material | 304 Stainless Steel |
| Width | 54.71 inch |
| Depth | 120.88 inch |
| Height | 100.19 inch |
| Insulation Thickness | 3.14 inch |
Model Number: CS-GBS-Start80
Afinox - INFINITY Start 80 Roll-In Blast Chiller & Freezer - Start80
Couldn't load pickup availability
| Weight | 1806 lb |
| Blast Chilling Capacity | 1102 lb |
| Freezing Capacity | 992 lb |
| Pan Capacity | 100 (GN 2/1 steam table pans) |
| Voltage | 220V |
| Hertz | 60Hz |
| Phase | 3 Ph |
| Amperage | 23 Amps |
| Refrigerating Power | 14970 W |
| Noise Level | 124 dB |
| Number of Probes | Multipoint core probe (4 reading points) |
| Temperature Range (Chill) | From 194°F to 37°F in 90 minutes |
| Temperature Range (Freeze) | From 194°F to -0.4°F in 240 minutes |
| Control System | 9 in Touchscreen |
| Refrigerant Gas | R404A |
| Installation Type | Freestanding |
| Material | 304 Stainless Steel |
| Width | 54.71 inch |
| Depth | 120.88 inch |
| Height | 100.19 inch |
| Insulation Thickness | 3.14 inch |
