Description
The Jet-Tech Undercounter Cup/Glasswasher is a durable, heavy-duty solution for transporting packages, supplies, and equipment.
Key highlights:
- Body, extenal housing, wash tank, and all chassis components in brushed stainless steel 304 18/10
- Noise 58 dBa thanks to utilization of double-wall insulated panels
- Upper and lower wash and rinse revolving arms constructed of stainless steel; easy to remove and clean without the need for tools
- Intergrated AISI 18/10 stainless steel booster with insulated lining
- Safety micro-switch on the door to interrupt wash pump action
- Independently-operated heating elements alternating between booster and wash tank
- Alternating heating resistors reducing maximum absorption thereby reducing energy costs
- Possibility of built-in or free-standing instalation
- Standard insulated top and side panels
- Wash pump protected with filter plus additional filter for overflow tube
- Door-opening with overall clearance of 10-inch (25 cm)
- Protective stainless steel shield for wash tank element
- Automatic fill and water level reguation of the wash tank
- Slide out intergrated front control panel Offers easy access for service
- Individual digital gauges for both wash and rinse temperatures
- Rack capacity: 15.75-inch × 15.75-inch (400 mm × 400 mm)
- Complete operating cycle: 145 seconds wash and 15 seconds rinse
- Wash tank capacity: 3.0 U.S. gallons (11 litres)
- Wash tank element: 2000 watts
- Wash temperature: 150°F (65°C)
- Booster capacity: 0.79 U.S. gallon (3.0 litres)
- Booster element: 2400 watts
- Booster (water) temperature: 185°F - 194°F (85°C - 90°C)
- Power supply: 208-240/60/1
- Amperage: 12.9 amps
- Motor-pump: 0.5 HP with thermal overload protection
- Maximum power rating: 2600 watts
- Water consumption: 0.53 U.S. gallon per cycle (2.0 litres)
- Water consumption per hour: 15 U.S. gallons (56.7 litres max.)
- Water supply: 1/2* hot water supply 140°F / 60°C
- Recommended pressure: 30 p.s.i. (dynamic) (PRV may be required)
- Water inlet connection: 3/4-inch male hose connector (hose included)
- Drain connection: 1-inch ID (25.4mm) max height 36-inch (915mm) (hose included)
- Shipping weight: 116 Ibs (53 kg)
Description
The Jet-Tech Undercounter Cup/Glasswasher is a durable, heavy-duty solution for transporting packages, supplies, and equipment.
Key highlights:
- Body, extenal housing, wash tank, and all chassis components in brushed stainless steel 304 18/10
- Noise 58 dBa thanks to utilization of double-wall insulated panels
- Upper and lower wash and rinse revolving arms constructed of stainless steel; easy to remove and clean without the need for tools
- Intergrated AISI 18/10 stainless steel booster with insulated lining
- Safety micro-switch on the door to interrupt wash pump action
- Independently-operated heating elements alternating between booster and wash tank
- Alternating heating resistors reducing maximum absorption thereby reducing energy costs
- Possibility of built-in or free-standing instalation
- Standard insulated top and side panels
- Wash pump protected with filter plus additional filter for overflow tube
- Door-opening with overall clearance of 10-inch (25 cm)
- Protective stainless steel shield for wash tank element
- Automatic fill and water level reguation of the wash tank
- Slide out intergrated front control panel Offers easy access for service
- Individual digital gauges for both wash and rinse temperatures
- Rack capacity: 15.75-inch × 15.75-inch (400 mm × 400 mm)
- Complete operating cycle: 145 seconds wash and 15 seconds rinse
- Wash tank capacity: 3.0 U.S. gallons (11 litres)
- Wash tank element: 2000 watts
- Wash temperature: 150°F (65°C)
- Booster capacity: 0.79 U.S. gallon (3.0 litres)
- Booster element: 2400 watts
- Booster (water) temperature: 185°F - 194°F (85°C - 90°C)
- Power supply: 208-240/60/1
- Amperage: 12.9 amps
- Motor-pump: 0.5 HP with thermal overload protection
- Maximum power rating: 2600 watts
- Water consumption: 0.53 U.S. gallon per cycle (2.0 litres)
- Water consumption per hour: 15 U.S. gallons (56.7 litres max.)
- Water supply: 1/2* hot water supply 140°F / 60°C
- Recommended pressure: 30 p.s.i. (dynamic) (PRV may be required)
- Water inlet connection: 3/4-inch male hose connector (hose included)
- Drain connection: 1-inch ID (25.4mm) max height 36-inch (915mm) (hose included)
- Shipping weight: 116 Ibs (53 kg)
Specifications
| Water Consumption | 0.53 U.S. gallon per cycle (2.0 litres) |
| Water Consumption Per Hour | 15 U.S. gallons (56.7 litres max.) |
| Height | 29.75 inch |
| Width | 20.25 inch |
| Depth | 20.25 inch |
| Amps | 12.9 Amps |
| Hertz | 60hz |
| Voltage | 208-240 Volts |
| Phase | Single Phase |
Jet-Tech
by
Jet-Tech
Model Number: CS-MVP-F-16DP
Jet-Tech - Undercounter Glasswasher - F-16DP (Pre-Order Now, ETA Mid January)
